Veracity OUTREACH Max PoE-powered LAN & PoE Extender VOR-ORM
Be the first to review this product
Quick Overview
OUTREACH Max doubles, triples or even quadruples the normal 330ft (100m) CAT5 cable run length for 100BaseT networks. It forwards both Ethernet and PoE for another 330ft (100m) using a patent-pending power-processing scheme, and multiple units can be employed in series for even longer distances, with no degradation in network speed or latency. OUTREACH Max itself is powered by a PoE network switch (or PoE injector) and so requires no separate power connection in the middle of the cable, making it extremely easy to connect and power IP cameras two or three times further than previously possible without going to fibre or installing midspan power sources.
Power Over Ethernet Articles
Veracity IP Transmission Catalogue 2010
Power Over Ethernet Articles
Veracity IP Transmission Catalogue 2010
Product Datasheets
Veracity OUTREACH Max PoE-powered LAN & PoE Extender VOR-ORM Datasheet (0.88MB)
Product Description
Why OUTREACH Max simplifies your network installations:
- Extends Ethernet cable installations to beyond 100 metres
- Forwards Power Over Ethernet (POE) to remote devices
- No power cable installation required
- Incorporates Power Promise™ technology for reliable power delivery
- Fully transparent – no restriction to network traffic
- Simple to install – works instantly
- Robust, compact and wall-mountable
- Supports all network devices
- Compatible with universal IEEE 802.3af POE standard
NB Please check the Maximum Distance table on the back page of the product datasheet for the maximum distance achievable for the POE Class of device that you are supplying. If you are in any doubt, please call and ask us.
- Extends Ethernet cable installations to beyond 100 metres
- Forwards Power Over Ethernet (POE) to remote devices
- No power cable installation required
- Incorporates Power Promise™ technology for reliable power delivery
- Fully transparent – no restriction to network traffic
- Simple to install – works instantly
- Robust, compact and wall-mountable
- Supports all network devices
- Compatible with universal IEEE 802.3af POE standard
NB Please check the Maximum Distance table on the back page of the product datasheet for the maximum distance achievable for the POE Class of device that you are supplying. If you are in any doubt, please call and ask us.
Product Questions
Questions on Veracity OUTREACH Max PoE-powered LAN & PoE Extender VOR-ORM
No questions asked yet
Ask Your Own Question
Additional Information
| Warranty | No |
