TP-Link TL-SF1009P 9-Port 10/100Mbps Desktop PoE Switch with 8-Port PoE+
SKU: TL-SF1009P
Contact Us for Stock Levels
Key Features:
- 9× 10/100 Mbps RJ45 ports
- 8× PoE ports transfer data and power on individual cables
- Works with IEEE 802.3af/at compliant PDs
- Supports PoE Power up to 30 W for each PoE port
- Supports PoE Power up to 65 W for 8 PoE ports
- Up to 250 m data and power transmitting range under Extend Mode
- Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application
- Isolation Mode allows one-click client traffic separation for higher security and performance
- Plug and play with no configuration required
Details
The TP-Link TL-SF1009P is a 9 Port 10/100Mbps unmanaged switch that has 8 PoE+ (Power over Ethernet) ports and can automatically detect and supply power to IEEE802.3af/at compliant Powered Devices (PDs). Both data and electrical power is transmitted along one cable, enabling users to expand their network even in areas where there are no power lines or outlets.
The TL-SF1009P can power up to 8 PoE ready devices including; wireless access points (APs), IP Cameras or IP Phones, etc. The unit features both a desktop and wall mountable design and provides users with outstanding performance and quality, and is a great option for expanding your network.
Power over Ethernet:
- Ports 1-8 are PoE enabled
- Overload arrangement
- If PoE PDs power consumption is over 65W, priority will be arranged among PoE ports
- Priority function to help protect the system
- Intelligent power management will kick in when the system power is overloaded
Highlight Performance:
- Up to 250m PoE power supply and data transmission under Extend Mode
- Priority Mode ensures high priority of Port 1-2 of the TL-SF1009P to guarantee the quality of sensitive application
- Isolation Mode easily divides traffic for Port 1-8 to avoid snooping and tampering, which improves LAN security and performance
Easy to Use:
- Easy to install and use
- No configuration is required
- Desktop and wall mountable design
Hardware Features | TL-SF1009P |
Interface | 9 x 10/100Mbps RJ45 Ports |
PoE Standard | 802.3af/at |
PoE Ports | Port 1-Port 8, up to 30W per port |
PoE Power Budget | 65W |
External Power Supply | output: 53.5V DC/1.31 A |
Max Power Consumption | 3.7W (with no PD connected) 77W (with 65W PD connected) |
Max Heat Dissipation | 12.617 BTU/hr (no PD connected) 262.57 BTU/hr (with 65W PD connected) |
Dimensions | 171 x 98 x 27mm |
Fan Quantity | Fanless |
