Wisenet PNM-9000VD 10MP Multi-Directional Camera

Availability: Contact Us for Stock Levels

£708.00 Incl VAT Excl VAT. £590.00

Hanwha Techwin PNM-9000VD

Make an Offer

If you would prefer to negotiate a lower price for this item with us, please enter your offer below. We'll then connect you to our Live Chat team who will review your offer as quickly as possible.

Quick Overview


The Wisenet PNM-9000VD is a 10 megapixel multi-directional camera featuring 2 x 5MP lens modules. This camera is able to simultaneously monitor two areas through multiple angles by installing two camera lenses in one camera.

Dependent on what area a user wants to cover, they are able to select from 3.7mm, 4.6mm and 7mm lenses to ensure they are getting the coverage desired.


This camera is not supplied with lenses. You must purchase your lens choices separately.

Available lenses:
- SLA-5M3700D (3.7mm)
- SLA-5M4600D (4.6mm)
- SLA-5M7000D (7mm)


The PNM-9000VD has an IP66 weatherproof-rated and IK10 vandal resistant-rated housing making it suitable for use in a wide range of applications, both indoors and outdoors. The multi-directional design makes it perfect for use in scenarios where there are more than one area of interest such as a reception area or in long or angled corridors.

This product is powered by PoE. Please note: this product does not come with a power supply.




Wisenet P Series User Manual
Wisenet P Series Quick Guide
Wisenet P Series Brochure
Wisenet Quick Guide
Wisenet Product Line Up

Product Datasheets

Wisenet PNM-9000VD 10MP Multi-Directional Camera Datasheet (0.53MB)


This product may not be immediately available from UK stock, in which case it will take 7 days to fetch it from their European warehouse.



Find use-IP on Youtube   Find out more at the use-IP forum    Find the correct firmware for your camera


Useful Wisenet Tools

- SmartViewer
- Wisenet WAVE
- Wisenet Device Manager


Key Features

- Exchangeable 2 x 5MP lens modules
- 3.7mm, 4.6mm, 7mm fixed lens
- Max. 30fps @ all resolution
- H.265, H.264, MJPEG codec, multi streaming support
- Intelligent video analytics, WiseStream II
- MicroSD/SDHC/SDXC memory 2 slots
- IP66, IK10, PoE




3.7mm - Horizontal field of view: 97.5°
4.6mm - Horizontal field of view: 77.9°
7mm - 50.7°

Focal Length Diagram

For help on figuring out which focal length is best for you please see here.




Lux Levels - For more information on Lux Levels please look here.

Lux levels


Additional Information

Weight 1250.0000
Image chip type N/A
Indoor / Outdoor Indoors or Outdoors
Ingress Protection IP66
POE built-in Yes
POE Class Class 3 (6.49-12.95W)
Max. Resolution 2560 X 1920
Supply Volts POE only
Lens Mount N/A
Aspect ratio 4:3
Megapixels 5 MP
Max. Images per second 30
ONVIF Compatible Yes
Power Consumption max. 12.95W
Warranty 3 Years
Launch Date May 2019
