828.00

Wisenet XNV-8081R 5MP Vandal-Resistant IR Network Dome Camera

Availability: Contact Us for Stock Levels

£828.00 Incl VAT Excl VAT. £690.00

Hanwha Techwin XNV-8081R

Make an Offer

If you would prefer to negotiate a lower price for this item with us, please enter your offer below. We'll then connect you to our Live Chat team who will review your offer as quickly as possible.

Quick Overview


The Wisenet XNV-8081R is a 5MP IR dome camera with a focal length of 3.9mm - 9.4mm and a 1/1.8" progressive scan CMOS chip.

Supported by image enhancing features such as back light compensation (BLC), 120dB wide dynamic range (WDR), and high light compensation (HLC), this camera gives a detailed, high quality image in low-light environments.

It also comes with features such as heat mapping, fog detection, sound classification, face detection, shock detection and motion detection.


Armed with an IR range of up to 50m, IP66/IP67 weather-proof housing, a working temperature of -50°C - 60°C and IK10+ vandal-proof housing, the XNV-8081R is perfect for outdoor environments, although it can be used either indoor or outside.

This camera is part of the Wisenet X plus series which means that it is made for easy installation, reducing the amount of time spent installing, setting up and maintenance adjustments. This is due to their 'drill, fix, clip, cover' installation method.

The XNV-8081R has on-board dual micro SD/SDHC/SDXC card slots giving up to 512GB extra storage. This works well with the supported WiseStream II, H.264 and H.265 compression which allows a large saving on storage and bandwidth usage .


Wisenet X Series User Manual
Wisenet X Series Brochure
Wisenet Quick Guide
Wisenet Product Line Up

Product Datasheets

Wisenet XNV-8081R 5MP Vandal-Resistant IR Network Dome Camera Datasheet (0.21MB)


This product can be powered by either PoE or a 12V DC PSU, we usually recommend PoE for ease of installation.

Please note: this product does not come with a power supply.


This product may not be immediately available from UK stock, in which case it will take 7 days to fetch it from their European warehouse.




Find use-IP on Youtube   Find out more at the use-IP forum   Find the correct firmware for your camera


Useful Wisenet Tools

- SmartViewer
- Wisenet WAVE
- Wisenet Device Manager


Frequently bought together

+
+
+

Key Features

- 5 megapixel resolution.
- Dual SD/SDHC/SDXC memory slots (Max. 512GB).
- Hallway View, WiseStream II Support.
- Day & Night (ICR), WDR (120dB), Defog.
- Video & audio analytics, Audio playback.
- PoE / 12VDC, Bi-directional audio support.
- 3.6 - 9.4mm motorized varifocal lens.
- IP66/IP67, IK10+, NEMA4X.
- Up to 50m IR view-able range for low light/no light monitoring.



3.9mm - 9.4mm: Horizontal field of view: 92.1° to 38.7°

Focal Length Diagram

For help on figuring out which focal length is best for you please see here.



Additional Information

Weight 1750.0000
Image chip size 1/1.8"
Image chip type Progressive Scan CMOS
Image Compression H.265/H.264
Audio Audio input/output (full duplex)
Indoor / Outdoor Indoors or Outdoors
Ingress Protection IP67
POE built-in Yes
POE Class Class 3 (6.49-12.95W)
Max. Resolution 2560 X 1920
Supply Volts 12V DC or PoE
Lens Mount auto-iris
Lens Focal Length 3.9~9.4mm
Viewing Angle Horizontal Field of View: 92.1˚ - 38.7˚, Vertical Field of View: 67.2˚ - 29˚, Diagonal Field of View: 119.9˚ - 48.6˚.
Aspect ratio N/A
Megapixels 5 MP
Supplied with lens Yes
IR Range Up to 50m
ONVIF Compatible Yes
Power Consumption max. 12.95W
Warranty 2 Years
Launch Date 2019
