Hikvision DS-2TXS2628-10P/QA/GLT/CH36S80 Solar-Powered Thermal Camera Kit
SKU: DS-2TXS2628-10P/QA/GLT/CH36S80
Contact Us for Stock Levels
Key features:
- Thermal Module 256x192 resolution; Optical Module 2688x1520 resolution
- Lens Focal Length - Thermal Module - 9.7mm; Optical Module - 8mm
- Temperature exception alarm for fire prevention
- Video content analysis: human/vehicle classification
- Embedded audible alert and strobe light
- IR and White Light Illumination up to 30m
- Bi-spectrum Image Fusion
- LTE-TDD/LTE-FDD/WCDMA 4G wireless network transmission
- Support Micro SIM card
- Wide Dynamic Range (WDR) up to 120dB
- Alarm Input/Output - 2 Input (0 to 5 VDC) / 2 Output (with configurable alarm response actions)
- 80W photovoltaic panel, 36Ah chargeable lithium battery
- Ingress Protection Rating - IP67
- High quality detector with 10 years guarantee
This product can be powered by 12VDC or PoE. We recommend using PoE.
Please note: this product does not come with a power supply.
Hikvision Thermal & Optical Bi-spectrum Camera User Manual
Hikvision Solar-Powered Thermal Camera Kit Quick Start Guide
Hikvision Product Catalogue
Please note: this product may not be immediately available from UK stock.
Please contact us before purchasing for a lead time.
Useful Hikvision Tools
- SADP Download
- IE Tab Download
- Hik-Connect
Details
The Hikvision DS-2TXS2628-10P/QA/GLT/CH36S80 is a solar-powered thermal camera kit that is powered by a lithium battery. It offers IR and white light illumination up to 30m and features high accurate VCA and temperature exception alarm for fire prevention. Supporting multiple standards including GSM, WCDMA and 4G LTE, the camera setups connect easily and wirelessly to the internet over mobile networks. With bi-spectrum image fusion, the details of the optical channel are displayed on the thermal channel, making for a fuller image. This camera is also embedded with audible alert and strobe light. It can be used in construction sites, farms, mobile tower and more.
Range Table
| VCA Range (Vehicles: 1.4m x 4m) | VCA Range (Humans: 1.8m x 0.5m) | Temperature Measurement (Object 0.2m x 0.2m) | Temperature Measurement (Object 1m x 1m) |
| 203.7m | 77.6m | 32.3m | 161.7m |
DORI stands for Detect, Observe, Recognise & Identify.
The DORI Distance provides users with a general overview of the camera's capability to distinguish people or objects within its field of view.
| Detection Range (Vehicles: 1.4m x 4m) | Detection Range (Humans: 1.8m x 0.8m) | Recognition Range (Vehicles: 1.4m x 4m) | Recognition Range (Humans: 1.8m x 0.5m) | Identification Range (Vehicles: 1.4m x 4m) | Identification Range (Humans: 1.8m x 0.5m) |
| 1239m | 404m | 310m | 101m | 155m | 50m |
