Hikvision DS-2DE7S425MW-AEB(F1)(S5) 4MP 25x Network Speed Dome PTZ Camera

Out of Stock
SKU
DS-2DE7S425MW-AEB(F1)(S5)

DS-2DE7S425MW-AEB(F1)(S5) Key Features

4MP Network Speed Dome Camera

25x Optical Zoom

Dual Channel Mode

AcuSense Technology

Live Guard Audio and Visual Alarm

Varifocal Lens: 4.5mm - 112.5mm Focal Length

Fixed Lens: 4mm Focal Length

Up To 200m IR Range

Up To 30m White Light Range

Powered By Hi-POE or 24 VAC

Audio and Alarm I/O's

IK10 Vandal Resistant Rating

IP66 Weather Resistant Rating


Hikvision Product Catalogue Hikvision Network Camera User Manual Hikvision DS-2DE7S425MW-AEB(F1)(S5) Quick Start Guide

Product Datasheets

Hikvision DS-2DE7S425MW-AEB(F1)(S5) 4MP 25x Network Speed Dome PTZ Camera Datasheet (1.05MB)

Find use-IP on Youtube   Find out more at the use-IP forum   Find the correct firmware for your camera



Useful Hikvision Tools

- SADP Download
- IE Tab Download
- Hik-Connect




Frequently bought together

  1. Hikvision DS-2DE7S425MW-AEB(F1)(S5) 4MP 25x Network Speed Dome PTZ Camera
  2. +
  3. Hikvision DS-7716NI-I4-16P 16 Channel Network Video Recorder
  4. +
  5. WD Purple 8TB SATA 6 Gb/s NAS Hard Drive WD80PUZX
  6. +
  7. Hikvision DS-1602ZJ Wall Mount Bracket
  8. +
  9. Hikvision DS-3E0106HP-E 4 Port Unmanaged Hi-PoE/PoE Switch
Total price: £0.00INCL VAT
Ex Vat: £0.00

The Hikvision DS-2DE7S425MW-AEB(F1)(S5) is a network speed dome camera featuring dual lenses to provide both a fixed overview and a PTZ channel. It also features 4MP resoltution and 25x optical zoom to allow users to zoom in to objects of interest in the distance.

With AcuSense technology the DS-2DE7S425MW-AEB(F1)(S5) focuses on human and vehicle classifications which greatly improves the alarm efficiency and effectiveness. This works hand in hand with the active strobe light and audio alarm feature that is used to warn off intruders.

Both lenses offer superb, high quality images in low light scenarios. The fixed lens provides 24/7 colorful images due to it's 1/1.8" sensor and supplement white LED light which can reach up to 30m. Whilst the varifocal lens pulls from Darkfighter technology, using WDR. HLC 3D DNR as well as built in IR illuminators that can reach up to 200m.

The DS-2DE7S425MW-AEB(F1)(S5) can be used both internally and externally. With a rating of IP66 the Speed Dome is able to withstand water, dust and dirt ingress succesfully. Also, witha a rating of IK10 the DS-2DE7S425MW-AEB(F1)(S5) is vandal resistant so is suitable for use in a range of public applications where it could be subject to vandal attempts. The camera also features defog mode,

The DORI distance gives users an overall idea of the cameras ability to distinguish people or objects within its field of view. It is calculated based on the camera sensor specification and the criteria given by EN 62676-4: 2015.

DORI DETECT OBSERVE RECOGNISE IDENTIFY

Definition

 25 px/m  63 px/m  125 px/m  250 px/m

Distance (Tele)

 1655.2m  656.8m   331.0m   165.5m



Users should power the camera via a Hi-POE injector or switch, or a 24 VAC mains supply. Unfortuantely these are not included with the purchase so we have listed our recomended Hi-POE injector in our Frequently Brought Together section above.

Please note, we strongly recommend this camera to be used with Hikvision -I series NVRs as opposed to the -K series NVRs as the best way to ensure compatibility. For more information please see our Technical Forum.

Specs
Image chip size [fixed focal] 1/1.8" [varifocal] 1/2.8"
Image chip type Progressive Scan CMOS
Image Compression H.265+/H.265/H.264+/H.264
Audio Audio I/O
Auto-Focus Yes
Indoor / Outdoor Indoors or Outdoors
Ingress Protection IP66
Colour / monochrome True Day/Night
POE built-in Yes
Max. Resolution 2560 X 1440
Min. low-light lux 0.0005
Supply Volts HPoE or 24V AC
Lens Mount Dual: Fixed and Varifocal
Lens Focal Length [fixed] 4mm [varifocal] 4.5mm - 112.5mm
Viewing Angle Horizontal Field of View, Fixed: 88.7°, Varifocal: 56.9 - 3.2°
Aspect ratio 16:9
Megapixels 4 MP
Supplied with lens Yes
IR Range Up to 200m
Max. Images per second 25
PSU included No
Power Consumption max. 42W
Warranty 3 Years
Launch Date October 2021
